Titanium Rectifier Introduction

The 60A 160V titanium rectifier delivers specialized power for advanced titanium surface treatments. Specifically, this high-frequency power supply is engineered for Plasma Electrolytic Oxidation (PEO) and high-performance anodizing processes on titanium and its alloys. Consequently, it enables the creation of superior ceramic and oxide coatings. Furthermore, these coatings enhance titanium's natural properties for demanding applications.

Technical Specifications

Parameter	Specification
Input Power	3-Phase 400VAC, 50/60Hz
DC Output	0-160V / 0-60A
Switching Frequency	100 Hz - 20 kHz Programmable
Pulse Modes	Unipolar, Bipolar, Asymmetric Custom Waveforms
Rise/Fall Time	< 20 µs
Control System	Dedicated Titanium Process Software with HMI
Process Libraries	TC4 (Ti-6Al-4V), Pure Titanium, Medical Grade Alloys
Data Acquisition	Real-time Coating Growth Monitoring & Analysis
Cooling System	Air Cooling
Protections	Titanium-Specific Process Safeguards, OVP, OCP, OTP

Available Standard Models (Customizable) of Titanium Rectifier

Anodizing Power Supply Model Selection (Any model can be customized)
General Anodizing Power Supply （Below 30V, with timer control head, for conventional anodizing）
Model	Output Current (A)	Output Voltage (V)	Power (KW)	Input Current (A)	Input Voltage (V)	Weight (KG)	W×L×H (mm)
YH200018	2000	18	36	60	380	50	400×500×630
YH300018	3000	18	54	90	380	70	400×500×630
YH300020	3000	20	60	100	380	100	500×620×1150
YH300024	3000	24	72	120	380	120	500×620×1150
YH400018	4000	18	72	120	380	120	500×620×1150
YH400020	4000	20	80	133	380	120	500×620×1150
YH400024	4000	24	96	160	380	120	500×620×1150
YH500018	5000	18	90	150	380	120	500×620×1150
YH500020	5000	20	100	167	380	120	500×620×1150
YH500024	5000	24	120	200	380	130	500×620×1150
YH600018	6000	18	108	180	380	130	500×620×1150
YH600020	6000	20	120	200	380	130	500×620×1150
YH600024	6000	24	144	240	380	180	500×620×1150
YH800018	8000	18	144	240	380	180	500×670×1450
Advanced Anodizing Power Supply （Above 30V, touch screen PLC control, for hard anodizing）
Model	Output Current (A)	Output Voltage (V)	Power (KW)	Input Current (A)	Input Voltage (V)	Weight (KG)	W×L×H (mm)
YY200040	2000	40	80	133	380	135	600×750×1300
YY200060	2000	60	120	200	380	150	600×750×1300
YY200080	2000	80	160	267	380	180	600×750×1300
YY300040	3000	40	120	200	380	200	600×750×1300
YY400050	4000	50	200	333	380	250	600×750×1300
YY400050	4000	60	240	400	380	250	800×1150×1300
YY500050	5000	50	250	417	380	300	800×1150×1300
YY500060	5000	60	300	500	380	300	800×1150×1300
YY600060	6000	60	360	600	380	300	800×1150×1300
YY600080	6000	80	480	800	380	300	800×1150×1300
YY5050	50	150	7.5	13	380	40	420×500×320

Power（KW） = Output Voltage（V） × Output Current（A）

We will provide:

The product comes with a one-year warranty and boasts a service life of over 10 years. It supports both Constant Current and Constant Voltage modes, and it also includes a programmable ramp-up function for current or voltage settings. For time-sensitive applications, you can use the timed operation mode. Moreover, the multi-segment function allows you to vary constant current or voltage levels over time. The device further offers an RS485 communication interface, automatic polarity reversal, and a minute-level timing function. If you need customization, please contact us for further details.

Hard Anodizing Power Supply — Touchscreen Control Unit

1.  ID

    Process/program number, used to select or switch between different stored recipes.

2.  Stage

    The current step number in a multi-step ladder process (supports up to 20 stages).

3.  Set_U

    Target set voltage value (DC 0–160V adjustable).

4.  Rise_T./sec

    Rise time (soft start time) in seconds, adjustable from 0–999 seconds.

5.  Keep_T./min

    Hold time in minutes/seconds, adjustable from 1–9999 seconds/minutes.

6.  Stage List (Set_I / Set_U / Rise_T / Keep_T)

    Parameter table for multi-step processes, supporting up to 20 stages. Each stage can be independently configured with target current, target voltage, ramp-up time, and hold time.

7.  RUN

    Start button to begin power output according to the selected process.

8.  OFF / CV

    - `OFF`: Stop button to halt power output.

    - `CV`: Constant Voltage mode for steady output voltage control.

9.  single stage

    Single-step mode, runs only the selected stage without multi-step cycling.

10. U/I curve

    Voltage/Current curve mode, controls the process primarily by current profile.

11. Power Good

    Power supply ready indicator, lights green when the unit is healthy and ready to start.

12. Menu

    Main menu button to access system settings, parameter configuration, fault logs, and stored recipes.

13. AH Reset

    Amp-hour reset button to clear the accumulated Act.AH value.

14. AH Show / Alarm Mode

    - `AH Show`: Amp-hour display toggle.

    - `Alarm Mode`: Configuration for fault response and alarm behavior.

15. Set AH

    Target amp-hour value for charge-based automatic stop control.

16. Act.AH

    Actual accumulated amp-hours (total charge consumed during the process).

17. Run Time

    Elapsed runtime timer for the current process.

18. U (Voltage)

    Real-time output voltage display (large digits, unit: V).

19. I (Current)

    Real-time output current display (large digits, unit: A).

Key Features of the Titanium Rectifier

• Titanium-Optimized Frequency Range: Firstly, this titanium rectifier operates in the 100 Hz - 20 kHz range. Specifically, it is tuned for titanium's electrochemical characteristics. Therefore, it promotes stable plasma discharge. Additionally, it enables controlled oxide growth during PEO processes.
• Advanced Waveform Control: Secondly, the system generates specialized asymmetric pulses. Specifically, these optimize coating biocompatibility and osseointegration properties. Therefore, this titanium rectifier is particularly valuable for medical implant surface engineering.
• Material-Specific Process Intelligence: Moreover, pre-programmed parameters simplify setup for common titanium alloys. For instance, it includes Ti-6Al-4V and CP-Ti profiles. Furthermore, the titanium rectifier adapts to different electrolyte chemistries. Thus, it ensures consistent results.
• High-Current Capacity: Additionally, with 60A output, this titanium rectifier supports processing of larger titanium components. Likewise, it handles batch operations efficiently. Consequently, it suits both R&D and small-to-medium scale production environments.

Applications & Advantages

This titanium rectifier addresses critical surface engineering challenges across high-value titanium applications. These include, for example:

In Aerospace Component Manufacturing, it creates wear-resistant, thermal barrier, and corrosion-protective coatings on titanium airframe and engine components. Specifically, the high-frequency control ensures uniform coatings on complex geometries. Therefore, it is essential for flight-critical parts.

For Medical Implant Production, the titanium rectifier enables precise surface modification of orthopedic and dental implants. Specifically, controlled PEO processes create bioactive, antimicrobial surfaces. Thus, they improve implant integration and patient outcomes. Furthermore, they meet stringent medical device regulations.

In Chemical Processing Equipment, it applies corrosion-resistant ceramic coatings to titanium valves, pumps, and heat exchangers. Additionally, these coatings extend service life in aggressive chemical environments. Therefore, they address cases where titanium's inherent corrosion resistance may be insufficient.

For High-Performance Automotive Applications, the titanium rectifier creates lightweight, durable coatings on titanium exhaust systems and connecting rods. Likewise, it treats other performance components. Consequently, these parts withstand extreme thermal and mechanical stresses.

In Research & Development Laboratories, scientists utilize this titanium rectifier's precise control to study titanium-electrolyte interactions. Furthermore, they develop new coating formulations. Additionally, they optimize surface properties for emerging applications in energy, electronics, and advanced manufacturing.

Ultimately, this 60A 160V titanium rectifier represents a specialized tool for advancing titanium surface technology. Specifically, it provides precise electrical control. Therefore, it unlocks titanium's full potential through advanced surface engineering. Thus, it enables innovations across aerospace, medical, industrial, and high-performance applications where titanium's unique properties are essential.

Why Choose This Titanium Rectifier?

Titanium-Specific Optimization: Firstly, the system is engineered specifically for titanium alloys. Therefore, this titanium rectifier delivers superior results compared to general-purpose power supplies. Additionally, it includes pre-programmed profiles for common titanium grades.

High-Frequency Performance: Secondly, the 20 kHz switching capability enables fine control of plasma discharge. Specifically, this promotes uniform coating formation on complex geometries. Thus, it ensures consistent quality.

Medical-Grade Precision: Moreover, the asymmetric pulse waveforms optimize biocompatibility. Therefore, this titanium rectifier is ideal for medical implant applications. Furthermore, it meets stringent regulatory requirements.

Industrial Reliability: Finally, robust air cooling ensures reliable operation. Specifically, it supports extended production runs. Thus, this titanium rectifier delivers consistent performance in manufacturing environments.

Frequently Asked Questions (FAQs) About Gaohui Power Supply

Q: Do you have a price list for your products?

A: Products with the same nominal specifications often serve different industries, and they may carry different detailed parameter requirements. These differences directly affect production costs and technical solutions, so final prices will vary accordingly. For this reason, we recommend you contact us directly to receive a precise and tailored quotation.

Q: How can I obtain detailed technical specifications and images for a specific product?

A: We assign specialized consultants to support each industry sector. If you need further information, simply reach out to us. After we confirm your request, we will immediately send you the full technical datasheets and product images you need.

Q: What should I do if I cannot find the specific output current and voltage specifications I require?

A: We focus on custom non-standard industrial power supplies, so we can fully adjust output current and voltage to match your exact needs. The products shown on our website only represent part of our actual range, as we do not list every model online. If you cannot find your desired specifications, please contact us directly. We will work with you to confirm your exact requirements, or we can guide you to select the most suitable parameters based on your industry standards. We will provide complete technical specifications and dimension drawings so you can fully understand the product.
