Tailored for small‑scale electrolytic smelting and laboratory refining tasks, the Electrolytic Smelting Rectifier provides precise 50A 36V stable DC output. In addition, it supports long‑time continuous operation to ensure repeatable electrolytic reaction results.
Electrolytic Smelting Rectifier supplies dedicated DC power for laboratory electrolytic smelting and metal refining work. Even so, many common power supplies suffer from current drift after hours of continuous operation. This unstable output brings inconsistent metal deposition and distorts experimental test data. Electrolytic smelting requires tightly controlled current and voltage to achieve predictable metal precipitation. Therefore, a purpose‑built rectifier becomes essential for reliable smelting test results.
This Electrolytic Smelting Rectifier adopts high‑frequency IGBT conversion architecture to minimise power fluctuation, with rated parameters of 50A and 36V. Operators adjust current and voltage across the full 0‑50A and 0‑36V range to match different ore samples and electrolyte formulas. As a result, lab staff can carry out metal recovery and refining tests without frequent parameter readjustment. Meanwhile, multi‑layer electronic protection guards against over‑voltage, over‑current and over‑temperature risks. It protects both test samples and internal modules during long‑time continuous operation.
This Electrolytic Smelting Rectifier optimises output waveform specially for electrochemical smelting reactions. As a result, it keeps high working efficiency under long‑duration partial‑load laboratory conditions. Many general‑purpose power sources lack targeted optimisation for smelting scenarios. By contrast, every unit finishes waveform calibration before leaving our factory. Researchers obtain more consistent experimental data across repeated test batches.
Fast response closed‑loop control holds current and voltage within narrow tolerance during electrolysis. Accordingly, metal precipitation stays uniform and improves the reliability of smelting test outcomes. In addition, built‑in memory can store multiple groups of process parameters. Operators can call saved parameter profiles directly instead of manual reset before each new test.
Engineers optimise the internal hardware layout for lab‑based electrolytic smelting applications. It delivers steady DC output for precious metal recovery, electrolytic refining and related electrochemical trials. This rectifier performs reliably for trial formula verification and small‑scale feasibility exploration.
| Parameter Category | Specific Item | Specification |
|---|---|---|
| Main Output | Rated Current | 50A |
| Rated Voltage | 36V | |
| Output Mode | Constant Current, Constant Voltage | |
| Cooling System | Cooling Type | Air‑cooled |
| Power Input | Input Power | AC 220V Single‑phase |
| Communication | Data Interface | RS485 |
| Safety Settings | Protection Items | Over‑voltage, Over‑current, Over‑temperature, Short‑circuit Protection |
| Application Scope | Typical Use | Laboratory electrolytic smelting, metal recovery, electrolytic refining |
We can provide: The product comes with a one‑year warranty and boasts a service life of over 10 years. It supports both Constant Current and Constant Voltage modes, and it also includes a programmable ramp‑up function for current or voltage settings. For time‑sensitive applications, you can use the timed operation mode. Moreover, the multi‑segment function allows you to vary constant current or voltage levels over time. The device further offers an RS485 communication interface, automatic polarity reversal, and a minute‑level timing function. If you need customization, please contact us for further details.
R&D laboratories, university chemistry departments and metal‑processing research centres widely deploy this Electrolytic Smelting Rectifier. For instance, researchers run small‑scale electrolytic smelting tests and carry out precious metal recovery trials from raw materials. They analyse metal separation efficiency and test different electrolyte formulations.
Apart from sample‑level smelting experiments, it acts as a reliable test platform for new‑process feasibility verification. Furthermore, it completes batches of parameter screening work. It generates credible experimental records for academic reports and lab‑scale process development.
We design and manufacture professional rectifier equipment for electrolytic smelting and electrochemical research scenarios. Our technicians complete full‑load ageing testing and waveform calibration on every Electrolytic Smelting Rectifier before shipment. It ensures stable output performance for repeated long‑hour laboratory operations.
Furthermore, we support custom adjustments on output range and auxiliary functions. We supply technical after‑sales guidance and spare‑part support, and we deliver trustworthy power solutions for your electrolytic smelting research projects.
Learn more about related products：1500A 12V Water-cooled Synchronous Rectifier
A: Products with the same nominal specifications often serve different industries, and they may carry different detailed parameter requirements. These differences directly affect production costs and technical solutions, so final prices will vary accordingly. For this reason, we recommend you contact us directly to receive a precise and tailored quotation.
A: We assign specialized consultants to support each industry sector. If you need further information, simply reach out to us. After we confirm your request, we will immediately send you the full technical datasheets and product images you need.
A: We focus on custom non-standard industrial power supplies, so we can fully adjust output current and voltage to match your exact needs. The products shown on our website only represent part of our actual range, as we do not list every model online. If you cannot find your desired specifications, please contact us directly. We will work with you to confirm your exact requirements, or we can guide you to select the most suitable parameters based on your industry standards. We will provide complete technical specifications and dimension drawings so you can fully understand the product.
