The Pretreatment Rectifier from Gaohui Rectifier supports electrocleaning, acid activation, and rinsing stages on plating lines. This Pretreatment Rectifier delivers stable DC for surface preparation. Furthermore, the Pretreatment Rectifier handles continuous duty in aggressive chemical environments. Therefore, line operators count on it daily.
Cooling: Forced Air | Application: Electrocleaning & Activation | Ripple: ≤3% | Input: 3-Phase
The 200A 12V rectifier powers alkaline electrocleaning tanks of 1000L to 2000L capacity. It removes oils and oxides from steel and zinc parts before plating. Specifically, a typical electrocleaning cycle runs at 5 to 10 A/dm² for 3 to 5 minutes. Furthermore, the rectifier supports both cathodic and anodic cleaning.
Moreover, this rectifier serves acid activation and reverse-current desmutting stations. Consequently, workpieces arrive at the plating stage fully active. The 3-phase input ensures stable output under heavy workshop loads.
Furthermore, Gaohui builds pretreatment rectifiers for both manual and automated lines. The 3-phase input provides enough current for 1000L to 2000L cleaning tanks. Consequently, job shops and OEM lines both rely on this model.
| Parameter | Value |
|---|---|
| AC Input Voltage | AC 380V ±10%, 3-phase |
| DC Output Current | 0–200A adjustable |
| DC Output Voltage | 0–12V adjustable |
| Cooling Method | Forced air |
| Ripple Factor | ≤3% |
| Control Mode | IGBT/PWM, CV/CC |
| Polarity | Cathodic / anodic selectable |
| Dimensions | 500 × 400 × 280 mm |
| Weight | 45 kg |
| Specifications subject to change. Custom designs available upon request. | |
We can provide:
The product comes with a one-year warranty and boasts a service life of over 10 years. It supports both Constant Current and Constant Voltage modes, and it also includes a programmable ramp-up function for current or voltage settings. For time-sensitive applications, you can use the timed operation mode. Moreover, the multi-segment function allows you to vary constant current or voltage levels over time. The device further offers an RS485 communication interface, automatic polarity reversal, and a minute-level timing function. If you need customization, please contact us for further details.
Related Models:
Smaller line? View Industrial Plating Rectifier 4000A for the plating stage.
Need stripping? Check the Stripping Rectifier.
