The Jewelry Plating Rectifier from Gaohui Rectifier powers fine gold, silver, and rhodium plating on rings, pendants, and earrings. This Jewelry Plating Rectifier delivers ripple-free DC output for bright, uniform coatings. Moreover, the Jewelry Plating Rectifier supports precise current control at low amperage. Therefore, jewelry makers achieve consistent finish quality batch after batch.
Cooling: Forced Air | Application: Jewelry & Accessories | Ripple: ≤2% | Accuracy: ±1%
The 100A 12V rectifier is designed for jewelry workshops racking up to 50 rings or 20 pendants per cycle. It handles gold flash, silver strike, and rhodium plating baths. Specifically, a typical gold flash cycle draws 30 to 60A at 6 to 8V for 3 to 5 minutes. Furthermore, the 12V output covers most acidic gold and silver chemistries.
Moreover, this rectifier suits small electronics contact plating where low ripple matters. The ≤2% ripple prevents cloudy rhodium finishes on watch casings. Consequently, every piece comes out mirror-bright.
Furthermore, the 12V output also covers silver strike and palladium plating. Many jewelry shops plate multiple metals on the same rack. Consequently, one rectifier handles gold, silver, and rhodium without switching units.
| Parameter | Value |
|---|---|
| AC Input Voltage | AC 220V ±10%, single phase |
| DC Output Current | 0–100A adjustable |
| DC Output Voltage | 0–12V adjustable |
| Cooling Method | Forced air |
| Ripple Factor | ≤2% RMS |
| Current Stability | ±1% |
| Control Mode | IGBT/PWM, CV/CC |
| Dimensions | 420 × 320 × 220 mm |
| Weight | 25 kg |
| Specifications subject to change. Custom designs available upon request. | |
We can provide:
The product comes with a one-year warranty and boasts a service life of over 10 years. It supports both Constant Current and Constant Voltage modes, and it also includes a programmable ramp-up function for current or voltage settings. For time-sensitive applications, you can use the timed operation mode. Moreover, the multi-segment function allows you to vary constant current or voltage levels over time. The device further offers an RS485 communication interface, automatic polarity reversal, and a minute-level timing function. If you need customization, please contact us for further details.
