This 1000A 12V water-cooled high-frequency rectifier is designed for high-load industrial production.
Water-cooled High-frequency Rectifier is a high-power industrial DC device with 1000A rated current and 12V rated voltage. Firstly, it adopts professional water-cooled structure to deliver excellent heat dissipation effect. Besides, we provide full customization to meet diverse on-site production requirements. Stable and low-ripple power output guarantees consistent working performance. Furthermore, it adopts advanced high-frequency circuits, so the equipment can run continuously under heavy load conditions. In addition, we tailor functions, parameters and overall structure according to actual working scenarios to provide targeted solutions.
Water-cooled High-frequency Rectifier features reliable performance, strong durability and high operational stability. To begin with, it is equipped with premium electronic components to maintain a low failure rate during long-term running. Meanwhile, the optimized high-frequency circuit effectively reduces output ripple for precise power supply. Moreover, reserved expansion interfaces support convenient function upgrades. Therefore, we can adjust output parameters and equipment dimensions freely as requested. The efficient water cooling system keeps temperature stable and extends overall service life. Lastly, it supports constant current, constant voltage, timed operation and multi-segment control to meet complex production demands.
| Parameter Item | Technical Specification |
|---|---|
| Rated Output Voltage | 0 ~ 12VDC (Adjustable) |
| Rated Output Current | 0 ~ 1000ADC (Adjustable) |
| Input Power | Three-phase AC 380V, 50/60Hz |
| Control Precision | ≤1% Full Scale |
| Protection Function | Over voltage, over current, short circuit, over temperature |
| Cooling Mode | Water Cooling |
| Communication Interface | RS485 |
| Operation Mode | Constant Current, Constant Voltage, Timed Operation |
| Additional Functions | Programmable ramp-up, multi-segment control, minute-level timing |
| Custom Item | Appearance, size, function, control logic |
Power（W） = Output Voltage（V） × Output Current（A）
We can provide:
The product comes with a one-year warranty and boasts a service life of over 10 years. It also supports both Constant Current and Constant Voltage modes, and it includes a programmable ramp-up function for current or voltage settings. For this reason, you can use the timed operation mode for time-sensitive applications. In addition, the multi-segment function allows you to vary constant current or voltage levels over time. The device further offers an RS485 communication interface and a minute-level timing function. Hence, please contact us for further details if you need customization.
Water-cooled High-frequency Rectifier is widely used in high-power electrochemical and surface treatment industries. For one thing, it works perfectly for electroplating, electrolysis, metal processing and related production lines. For another, it is also applicable to large-scale industrial workshops and round-the-clock continuous production. Even if you run it under long-time heavy loads, this customized rectifier can adapt to various working cycles. Accordingly, we can adjust relevant parameters to fit your actual production conditions.
We are a professional manufacturer focusing on customized industrial power products. First of all, our experienced R&D team completes customized design and production efficiently. Secondly, all products pass strict quality tests to meet industrial safety standards. What’s more, we support flexible orders and ensure timely delivery. Apart from that, we also provide comprehensive after-sales guidance and technical support to solve operational issues promptly. Customization is our core strength, and we create stable and reliable power solutions for all industries. In conclusion, our products enjoy long service life and consistent performance.
Learn more about related products:Commutating Rectifier
A: Products with the same nominal specifications often serve different industries, and they may carry different detailed parameter requirements. These differences directly affect production costs and technical solutions, so final prices will vary accordingly. For this reason, we recommend you contact us directly to receive a precise and tailored quotation.
A: We assign specialized consultants to support each industry sector. If you need further information, simply reach out to us. After we confirm your request, we will immediately send you the full technical datasheets and product images you need.
A: We focus on custom non-standard industrial power supplies, so we can fully adjust output current and voltage to match your exact needs. The products shown on our website only represent part of our actual range, as we do not list every model online. If you cannot find your desired specifications, please contact us directly. We will work with you to confirm your exact requirements, or we can guide you to select the most suitable parameters based on your industry standards. We will provide complete technical specifications and dimension drawings so you can fully understand the product.
