Built for heavy‑duty electrowinning workflows, the 3000A 24V Water‑Cooled Electrolytic Copper Extraction Rectifier delivers consistent high‑current DC output. Meanwhile, its efficient water‑cooled design handles continuous heavy loads common in metal extraction plants.
The 3000A 24V Water‑Cooled Electrolytic Copper Extraction Rectifier is a heavy‑duty industrial power supply purpose‑built for electrolytic copper extraction and electrowinning processes. Copper electrowinning runs around‑the‑clock under extreme high‑current conditions, and minor current ripple or output drift will directly lower copper cathode purity and reduce overall metal recovery efficiency. Many general‑purpose rectifiers struggle to hold stable performance during days‑long continuous runs, bringing unstable deposition rates and more finished‑product impurities. Therefore, process‑oriented power hardware forms a critical foundation for consistent electrolytic copper production.
This 3000A 24V Water‑Cooled Electrolytic Copper Extraction Rectifier leverages high‑frequency IGBT conversion hardware optimized for electrowinning load profiles. It offers stepless adjustment across 0‑3000A and 0‑24V, adapting to varying electrolyte compositions and tank‑house operating conditions. The closed‑loop water‑cooled structure effectively dissipates massive heat generated at full‑current output, avoiding thermal drift that distorts power output. Comprehensive multi‑layer protection guards against over‑current, over‑voltage and over‑temperature risks, cutting unplanned downtime for your extraction lines.
Unlike generic industrial power units, this 3000A 24V Water‑Cooled Electrolytic Copper Extraction Rectifier carries waveform tuning specifically for copper electrowinning reactions. It maintains solid energy efficiency even under prolonged full‑load cycles, which helps lower overall power consumption for metal extraction workshops. Every unit goes through full‑load ageing and ripple testing prior to shipment, so production teams get predictable deposition quality across long production campaigns.
Fast‑acting closed‑loop regulation compensates real‑time deviations triggered by electrolyte temperature swings or bath concentration changes. Accordingly, copper deposition speed stays steady and cathode impurity levels remain well‑controlled. On‑board memory can store multiple sets of production parameters; operators can recall saved profiles quickly instead of repeating manual setup for different feed materials.
Constructed to withstand humid, corrosive workshop air typical of hydrometallurgical sites, the water‑cooled layout prevents performance degradation caused by overheating. This rectifier fits perfectly for both newly‑erected extraction lines and upgrade retrofits of existing electrolytic tank systems.
| Parameter Category | Specific Item | Specification |
|---|---|---|
| Rated Output | Rated Current | 3000A |
| Rated Voltage | 24V | |
| Working Mode | Operation Type | Constant Current / Constant Voltage |
| Cooling System | Cooling Method | Closed‑loop Water Cooling |
| Input Power | Input Voltage | AC 380V Three‑phase |
| Communication Interface | Data Port | RS485 |
| Safety Protection | Protection Functions | Over‑current, Over‑voltage, Over‑temperature, Short‑circuit Protection |
| Applicable Scenarios | Main Applications | Electrolytic copper extraction, copper electrowinning, hydrometallurgical metal recovery |
We can provide: The product comes with a one‑year warranty and boasts a service life of over 10 years. It supports both Constant Current and Constant Voltage modes, and it also includes a programmable ramp‑up function for current or voltage settings. For time‑sensitive applications, you can use the timed operation mode. Moreover, the multi‑segment function allows you to vary constant current or voltage levels over time. The device further offers an RS485 communication interface, automatic polarity reversal, and a minute‑level timing function. If you need customization, please contact us for further details.
This 3000A 24V Water‑Cooled Electrolytic Copper Extraction Rectifier finds wide deployment within hydrometallurgical plants, metal‑recovery facilities and pilot‑scale metallurgical test sites. Plant operators rely on it for electrolytic copper electrowinning from leach solutions, cathode metal production and process‑parameter validation for new extraction recipes.
It handles continuous round‑the‑clock production as well as trial‑run testing for process improvement projects. Stable DC output helps facilities raise copper cathode purity, cut reject rates and maximise metal yield from raw leach liquors.
We design and manufacture high‑current rectifiers tailored for hydrometallurgical extraction workflows. Our 3000A 24V Water‑Cooled Electrolytic Copper Extraction Rectifier is calibrated for the harsh continuous‑run demands of copper electrowinning, outperforming general‑purpose power supplies in real tank‑house conditions.
Each unit completes full‑load ageing and waveform calibration before dispatch. Custom adjustments for output range, cooling configuration and auxiliary features are available on request. Backed by practical process‑relevant technical guidance and reliable after‑sales support, we deliver robust power solutions for your electrolytic copper extraction projects.
Learn more about related products：200A 12V Air-cooled Electrolytic Polishing Rectifier
A: Products with the same nominal specifications often serve different industries, and they may carry different detailed parameter requirements. These differences directly affect production costs and technical solutions, so final prices will vary accordingly. For this reason, we recommend you contact us directly to receive a precise and tailored quotation.
A: We assign specialized consultants to support each industry sector. If you need further information, simply reach out to us. After we confirm your request, we will immediately send you the full technical datasheets and product images you need.
A: We focus on custom non-standard industrial power supplies, so we can fully adjust output current and voltage to match your exact needs. The products shown on our website only represent part of our actual range, as we do not list every model online. If you cannot find your desired specifications, please contact us directly. We will work with you to confirm your exact requirements, or we can guide you to select the most suitable parameters based on your industry standards. We will provide complete technical specifications and dimension drawings so you can fully understand the product.
