A hard chrome power supply is a power supply device specifically designed for hard chrome plating, a process that improves the surface properties of a metal by depositing a layer of hard chrome metal onto it. The hard chrome power supply provides stable current and voltage to ensure the smooth operation of the plating process.
| InputOutput | Voltage | Single-phase 220V/Three-phase 380V±10%, other options available upon request |
| Frequency | 50Hz/60Hz, other options available upon request | |
| Frequency ModeInputOutputFrequency ModeInputOutput | Current | 0-Maximum value (A) adjustable (customizable up to 100,000A) |
| Voltage | 0-Maximum value (V) adjustable (customizable up to 10,000V) | |
| Power | Output rated voltage x rated current = Power | |
| Waveform | Square wave (standard), positive pulse, positive/negative pulse, smooth wave | |
| Voltage Regulation Accuracy | ≤±0.1% (measurement range 10-100%) | |
| Current Regulation Accuracy | ≤±0.1% (measurement range 10-100%) | |
| Frequency Mode | Frequency | Low, medium, and high frequency modes, 100-9900Hz (customer selectable within this range) |
| Duty Cycle | 10-100% (customer selectable within this range) | |
| Operating Mode | Switchable current or voltage regulation function | |
| Ripple Coefficient | <1% | |
| Overall Efficiency | ≥92% (rated operating conditions) | |
| Cooling Method | Water-cooled/air-cooled type (customizable) | |
| Timing Function | Cumulative ampere-hour, ampere-hour, and time control | |
| Operating Status | Capable of long-term full-load operation | |
| Protection Functions | Overcurrent, overheat, undervoltage, and overvoltage protection | |
| Optional Functions | RS485 communication/analog input 4-20mA/remote start/stop interface, etc. | |
| Control Program Customization | Examples include multi-stage process settings, multi-stage time control, and automatic polarity reversal. | |
1. High stability: Hard chrome plating power supplies offer high stability, providing constant current and voltage to ensure the stability and consistency of the electroplating process.
2. High efficiency: Utilizing advanced circuit design and control technology, hard chrome plating power supplies are highly efficient, enabling fast and efficient completion of electroplating tasks.
3. Adjustability: Hard chrome plating power supplies typically feature adjustable parameters such as current and voltage to adapt to different materials and process requirements, achieving optimal electroplating results.
4. Safety: Hard chrome plating power supplies are equipped with overcurrent, overvoltage, and overheat protection functions to ensure safe operation of the equipment and prevent accidents.
Since its inception, the company has adhered to a market-oriented approach, with technological innovation as the core of its development. Through continuous innovation and upgrading, and by improving its scientific research and technology, it has successively obtained software copyright, software product, patent certificates, and CE certification, and has been recognized as a high-tech enterprise, one of China's top ten power supply brands, and a science and technology-based SME. Simultaneously, the company's domestically developed and innovative products have gradually replaced imported products.
