Product Introduction of Plating Power Supply

This Plating Power Supply is a professional core power source for industrial electroplating. Firstly, it converts AC power into stable DC or pulse power, solving common issues like uneven coating and poor adhesion. Moreover, as a custom-focused product, it supports flexible parameter adjustment to fit decorative, functional, and precision plating needs. Additionally, its rugged industrial design ensures stable long-term operation, suitable for all-scale electroplating workshops and easy integration into existing lines.

Core Selling Points of Plating Power Supply

- Stable output for uniform, dense coatings

- High efficiency to reduce operational costs

- Fully customizable for diverse plating processes

- Comprehensive protection to avoid production interruption

- Easy to operate and maintain

Product Advantages of Plating Power Supply

Firstly, this Plating Power Supply adopts advanced high-frequency IGBT technology, achieving ≥90% efficiency and minimizing energy waste. Meanwhile, its precise control ensures stable output with ≤3% ripple, improving coating quality. Furthermore, it supports DC/pulse mode switching, and customization is our core strength—we adjust parameters, cooling, and interfaces per customer needs. In addition, full protection functions and industrial-grade components ensure durability in harsh workshop environments.

Technical Parameters

Model	Output Current (A)	Output Voltage (V)	Power (kW)	Input Current (A)	Input Voltage (V)	Weight (kg)	W×L×H (mm)
ZJ100015	1000	15	15	25	380	60	390×480×250
ZJ200015	2000	15	30	50	380	60	430×480×250
ZJ300015	3000	15	45	75	380	60	520×730×300
ZJ400015	4000	15	60	100	380	100	570×730×300
ZJ500012	5000	12	60	100	380	120	570×770×250
ZJ600015	6000	15	90	150	380	130	550×880×250
ZJ800015	8000	15	120	200	380	180	500×670×1450
ZJ1000015	10000	15	150	252	380	250	600×800×1750
ZJ1200015	12000	15	180	303	380	300	800×1350×1500
ZJ1500018	15000	18	270	454	380	350	860×1450×1550
ZJ1800020	18000	20	360	606	380	350	860×1450×1850
ZJ2000015	20000	15	300	505	380	400	860×1450×1850
ZJ2500015	25000	15	375	631	380	450	880×1530×2150
ZJ3000015	30000	15	450	757	380	350	880×1530×2540
ZJ8000015	80000	15	1200	2020	380	491	880×1530×2540
ZJ1000001	100000	15	1500	2525	380	650	880×1530×2650

The product comes with a one-year warranty and boasts a service life of over 10 years. It supports both Constant Current and Constant Voltage modes, and it also includes a programmable ramp-up function for current or voltage settings. For time-sensitive applications, you can use the timed operation mode. Moreover, the multi-segment function allows you to vary constant current or voltage levels over time. The device further offers an RS485 communication interface, automatic polarity reversal, and a minute-level timing function. If you need customization, please contact us for further details.

Smart Remote-Controlled Headband with Timer and Vibration Functions

1.  6cm screw fixing hole

Mounting hole for securing the control panel.

2.  Output voltage display

Shows real-time output voltage (unit: V).

3.  Output current display

Shows real-time output current (unit: A).

4.  Timing/ampere display

Shows timer count or cumulative ampere-minute value for process control.

5.  Manual/automatic indicator light

Indicates whether the unit is in manual (local) or automatic (remote/RS485) control mode.

6.  Power on/off indicator light

Shows the power supply’s on/off status.

7.  Stable voltage/stable current indicator

Indicates operation in constant voltage (CV) or constant current (CC) mode.

8.  ON/OFF button

Controls power output start/stop.

9.  CV/CC button

Switches between constant voltage (CV) and constant current (CC) operating modes.

10. Output current or voltage adjustment knob

Adjusts output voltage/current; click to switch between quick and fine adjustment modes.

11. Automatic/Manual button

Toggles control mode between automatic (RS485 communication) and manual (local control).

12. Up/down buttons

Adjust values or navigate menu options.

13. SET button

Enters parameter settings (timing, ampere-counter, communication, etc.).

14. RX2/TX2

Secondary RS485 communication port (receive/transmit).

15. RX1/TX1

Primary RS485 communication port (receive/transmit).

16. RS485 communication interface

Wiring port for the RS485 communication bus.

17. Host control cable

Connection port for linking to the main power supply unit.

18. Timing indicator light

Lights when the timer function is active.

19. Ampere Counter Indicator

Lights when the cumulative ampere-minute function is active.

Scope of Application

This Plating Power Supply is widely used in decorative, functional, and precision electroplating for hardware, electronics, automotive, and aerospace industries. Moreover, it fits all-scale workshops and automated lines, and is suitable for special processes like electroforming and electrolytic polishing. Additionally, its customizability ensures adaptability to new technologies and laboratory R&D.

Why Choose US

Firstly, we have rich experience in Plating Power Supply R&D and focus on custom solutions. Secondly, our professional team designs exclusive products per customer needs, with strict quality tests and CE/ISO certifications. Moreover, we provide fast delivery, on-site commissioning, and comprehensive after-sales support, making us a trusted partner for electroplating enterprises.

Learn more about related products:Electron Commutator Rectifier

Frequently Asked Questions (FAQs) About Gaohui Power Supply

Q: Do you have a price list for your products?

A: Products with the same nominal specifications often serve different industries, and they may carry different detailed parameter requirements. These differences directly affect production costs and technical solutions, so final prices will vary accordingly. For this reason, we recommend you contact us directly to receive a precise and tailored quotation.

Q: How can I obtain detailed technical specifications and images for a specific product?

A: We assign specialized consultants to support each industry sector. If you need further information, simply reach out to us. After we confirm your request, we will immediately send you the full technical datasheets and product images you need.

Q: What should I do if I cannot find the specific output current and voltage specifications I require?

A: We focus on custom non-standard industrial power supplies, so we can fully adjust output current and voltage to match your exact needs. The products shown on our website only represent part of our actual range, as we do not list every model online. If you cannot find your desired specifications, please contact us directly. We will work with you to confirm your exact requirements, or we can guide you to select the most suitable parameters based on your industry standards. We will provide complete technical specifications and dimension drawings so you can fully understand the product.
