The Hard Chrome Rectifier from Gaohui Rectifier delivers 15000A at 16V for heavy-duty hard chrome lines. This Hard Chrome Rectifier powers hydraulic cylinders, printing rollers and large fixture racks with stable DC current. Furthermore, the Hard Chrome Rectifier uses water-cooled IGBT stages that hold tight current stability under full load. Consequently, plating shops rely on it for thick wear-resistant chrome deposits. Moreover, heavy hard chrome lines facilities select this Hard Chrome Rectifier for its water cooled design and 15000A capacity that keeps deposition rates predictable. Consequently, production planners factor it into daily schedules without derating concerns.
Cooling: Water Cooled | Application: Heavy Hard Chrome Lines | Ripple: ≤5% | Interface: RS485/PLC
The 15000A 16V rectifier is specifically engineered for hard chrome tanks between 8000L and 12000L, where current density often reaches 30-60 A/dm2. It is ideal for rebuilding hydraulic cylinder rods, piston rods and large rollers that demand deposit thickness above 100 microns. For example, a cylinder reconditioning plant can plate a 2-meter rod in a single pass. Furthermore, the 16V headroom covers the voltage drop across bus bars, rack contacts and the bath itself. Moreover, the 380V output range provides useful headroom for bus-bar losses, contact resistance and cooler electrolytes. In addition, the RS485, optional PLC port allows remote monitoring.
Moreover, this rectifier supports automatic polarity reversal for periodic reverse chrome plating, which improves adhesion on hardened steel. In addition, the water-cooled cabinet suits continuous three-shift production without derating. Consequently, customers use it for aerospace landing-gear components, marine shafts and heavy machine tool parts where reject rates must stay low. Moreover, operators appreciate the straightforward layout and clearly marked controls on this Hard Chrome Rectifier. Finally, the service team at Gaohui Rectifier responds to spare-part requests quickly, which keeps the line running.
| Parameter | Value |
|---|---|
| AC Input Voltage | AC 380V ±10%, three phase |
| DC Output Current | 0–15000A adjustable |
| DC Output Voltage | 0–16V adjustable |
| Cooling Method | Water cooled |
| Ripple Factor | ≤5% RMS |
| Control Mode | IGBT/PWM, CV/CC |
| Communication | RS485, optional PLC |
| Dimensions | 1400 × 900 × 1800 mm |
| Weight | 1100 kg |
| Special Feature | Automatic polarity reversal optional |
| Specifications subject to change. Custom designs available upon request. | |
We can provide:
The product comes with a one-year warranty and boasts a service life of over 10 years. It supports both Constant Current and Constant Voltage modes, and it also includes a programmable ramp-up function for current or voltage settings. For time-sensitive applications, you can use the timed operation mode. Moreover, the multi-segment function allows you to vary constant current or voltage levels over time. The device further offers an RS485 communication interface, automatic polarity reversal, and a minute-level timing function. If you need customization, please contact us for further details.
Related Models:
Need less power? View the 6000A 16V Hard Chrome Plating Rectifier.
Need higher output? Check the 60000A 15V High Power Chrome Rectifier.
A: Products with the same nominal specifications often serve different industries, and they may carry different detailed parameter requirements. These differences directly affect production costs and technical solutions, so final prices will vary accordingly. For this reason, we recommend you contact us directly to receive a precise and tailored quotation.
A: We assign specialized consultants to support each industry sector. If you need further information, simply reach out to us. After we confirm your request, we will immediately send you the full technical datasheets and product images you need.
A: We focus on custom non-standard industrial power supplies, so we can fully adjust output current and voltage to match your exact needs. The products shown on our website only represent part of our actual range, as we do not list every model online. If you cannot find your desired specifications, please contact us directly. We will work with you to confirm your exact requirements, or we can guide you to select the most suitable parameters based on your industry standards. We will provide complete technical specifications and dimension drawings so you can fully understand the product.
