Output: 12V DC / 12000A (144kW)
Core Purpose: High-Volume Decorative Chrome Plating
Ripple: ≤ 2% RMS (Ultra-Low for Brightness)
Best For: Automotive Trim, Faucets, Wheels, Consumer Electronics, High-Speed Rack & Barrel Lines
The 12000A 12V decorative chrome rectifier is engineered for the highest-volume plating facilities. Specifically, it delivers an unprecedented 12000 amperes of exceptionally clean DC power, which is essential for achieving brilliant, mirror-finish chrome on consumer goods at maximum production speed. Therefore, it is the definitive power source for automated, high-throughput decorative plating lines.
| InputOutput | Voltage | Single-phase 220V/Three-phase 380V±10%, other options available upon request |
| Frequency | 50Hz/60Hz, other options available upon request | |
| Frequency ModeInputOutputFrequency ModeInputOutput | Current | 0-Maximum value (A) adjustable (customizable up to 100,000A) |
| Voltage | 0-Maximum value (V) adjustable (customizable up to 10,000V) | |
| Power | Output rated voltage x rated current = Power | |
| Waveform | Square wave (standard), positive pulse, positive/negative pulse, smooth wave | |
| Voltage Regulation Accuracy | ≤±0.1% (measurement range 10-100%) | |
| Current Regulation Accuracy | ≤±0.1% (measurement range 10-100%) | |
| Frequency Mode | Frequency | Low, medium, and high frequency modes, 100-9900Hz (customer selectable within this range) |
| Duty Cycle | 10-100% (customer selectable within this range) | |
| Operating Mode | Switchable current or voltage regulation function | |
| Ripple Coefficient | <1% | |
| Overall Efficiency | ≥92% (rated operating conditions) | |
| Cooling Method | Water-cooled/air-cooled type (customizable) | |
| Timing Function | Cumulative ampere-hour, ampere-hour, and time control | |
| Operating Status | Capable of long-term full-load operation | |
| Protection Functions | Overcurrent, overheat, undervoltage, and overvoltage protection | |
| Optional Functions | RS485 communication/analog input 4-20mA/remote start/stop interface, etc. | |
| Control Program Customization | Examples include multi-stage process settings, multi-stage time control, and automatic polarity reversal. | |
1. This product is a special power supply based on a standard high-frequency rectified electroplating power supply. The output voltage is 6-18V, possessing all the functions of a standard electroplating power supply, making it an ideal product for special electroplating surface treatments such as hard chrome plating.
2. It features multi-step stepped power supply, multi-step soft-start time setting, automatic reset, and other functions to meet different process requirements.
3. The power supply has voltage regulation and current limiting functions or current regulation and voltage limiting functions, with control and display accuracy ≤1%.
4. The equipment has multiple protection functions such as output overcurrent, over-temperature, and input phase loss. The product is stable and reliable, with a reasonable internal structure and all electronic components are sealed, reducing the impact of the external environment on the internal components.
5. The control system can be selected from digital control, analog control, or RS485 communication control, and can also be equipped with a 4-20mA, 0-10V standard control signal interface.
This mega-capacity decorative chrome rectifier delivers unparalleled production advantages. Primarily, its immense, clean power enables the highest possible line speeds without sacrificing the brilliant aesthetic quality demanded by the market. Secondly, its exceptional stability and low ripple guarantee consistent color, brightness, and coverage across every part, minimizing reject rates. Thirdly, the modular, redundant design ensures near 100% uptime, which is vital for continuous production schedules. Finally, its high efficiency and intelligent control significantly reduce energy and chemical consumption per part, improving overall profitability.
