This high‑output electrophoresis rectifier delivers robust adjustable DC for demanding coating workflows. Furthermore, it maintains steady performance under combined high‑current and high‑voltage continuous operation.
Gaohui Power Supply develops the 300A 400V High‑Output Electrophoresis Rectifier for heavy‑duty electrophoresis production plants. To start with, many large‑size workpiece projects demand both ample amperage and elevated voltage to achieve qualified thick protective films, yet ordinary rectifiers cannot satisfy such dual‑demanding process conditions. Because simultaneous high‑current and high‑voltage operation easily triggers output drift and defective coating layers, this Power Supply tightly stabilises voltage and current values to prevent such production failures. What is more, it runs smoothly for round‑the‑clock mass production as well as special‑job custom batches.
This high‑output electrophoresis rectifier supports cathodic plus anodic electrophoresis processing. Apart from that, its broad 0‑400V adjustment scope meets strict technical standards for oversized structural metal pieces. Meanwhile, upgraded reinforced IGBT modules keep stable output even when workshops carry out long‑time heavy‑load runs amid corrosive chemical fume environments.
‑ 0‑400V adjustable DC voltage, 0‑300A adjustable DC current; voltage and current regulation accuracy within one percent
‑ Ultra‑low‑ripple pulse output with ripple factor ≤2%, delivers homogeneous coating for large‑sized parts with complex geometries
‑ Dual constant‑current and constant‑voltage working modes, supports flexible ramp‑up rate fine‑tuning
‑ Integrated digital Ah counter and minute‑based programmable timer to support unattended multi‑shift plant operation
‑ RS485 Modbus RTU communication port, enables site personnel to link the device directly to factory‑wide automation platforms
We engineer this high‑output electrophoresis rectifier with heavy‑duty IGBT power topology, so it reaches Power Supply conversion efficiency above ninety percent. Even when it outputs full‑rated 300A under 400V for extended working hours, it keeps heat generation under effective control and lowers risks of unexpected thermal shutdown. In addition, forced‑air cooling structure cuts daily maintenance burdens for on‑site technicians.
Its native automatic polarity reversal helps operators simplify tank cleaning and electrode maintenance routines. As a result, workers do not need to rewire hardware manually every time they toggle process polarity. Besides, multi‑segment programming allows users to set multi‑stage voltage‑current profiles; users can match complex high‑voltage coating recipes and broaden compatibility for diverse paint formulations.
Our technical team fits internal circuits with anti‑corrosion and anti‑interference electronic components. Accordingly, the rectifier retains trustworthy output inside humid production spaces filled with chemical vapours. It greatly reduces colour deviation and uneven film thickness caused by external electrical disturbance.
| Parameter Category | Specific Item | Specification |
|---|---|---|
| Input Parameters | AC Input Power Supply | Three‑phase AC 380V, ±10% tolerance, 50‑60Hz |
| DC Output Parameters | Output Voltage Range | Zero to 400V adjustable |
| DC Output Parameters | Output Current Range | Zero to 300A adjustable |
| DC Output Parameters | Voltage Regulation Accuracy | Within one percent |
| DC Output Parameters | Current Regulation Accuracy | Within one percent |
| DC Output Parameters | Ripple Factor | Within two percent |
| Control and Automation Functions | Operation Modes | Constant Current, Constant Voltage |
| Control and Automation Functions | Auxiliary Control Devices | Digital ampere‑hour meter, minute‑level programmable timer, automatic polarity reversal |
| Control and Automation Functions | Programming Functions | Programmable current‑voltage ramp‑up, multi‑segment parameter setting |
| Physical and Communication Parameters | Cooling Mode | Forced air cooling |
| Physical and Communication Parameters | Protection Grade | IP21 for indoor application |
| Physical and Communication Parameters | Communication Protocol | RS485 Modbus RTU |
| Physical and Communication Parameters | Working Efficiency | Above ninety percent |
| Physical and Communication Parameters | Size and Weight | Fully customizable based on customer demands |
We can provide:
We deliver this unit with one‑year warranty and over 10‑year expected service life. Constant‑current / constant‑voltage modes and ramp‑up fine‑tuning come as standard configurations. Furthermore, timed operation cycles and multi‑segment profiles adapt to heavy‑load high‑voltage coating assignments. This device comes equipped with RS485 interface and automatic polarity reversal. Get in touch to discuss your custom Power Supply requirements.
This high‑output electrophoresis rectifier suits high‑power metal finishing tasks that combine high voltage and high current. Above all, it serves oversized structural components, heavy‑duty machinery parts and large‑capacity loading racks requiring thick anti‑corrosion coating layers.
Additionally, production crews deploy this equipment on production lines processing bulky single‑piece workpieces or mixed high‑density part batches. Manufacturing plants opt for this model whenever standard‑spec power units cannot reach required high‑power process thresholds.
It works well with epoxy, acrylic and polyurethane electrophoresis paints for both cathodic and anodic treatment workflows. Thanks to its steady 300A output, it achieves complete and even coating coverage for extra‑large components. Likewise, it delivers solid performance for new‑formula testing batches and non‑stop high‑volume assembly‑line production.
Gaohui Power Supply creates custom‑tailored High‑Output Electrophoresis Rectifier for heavy‑power surface‑treatment manufacturers, and bespoke modification capability forms our key market advantage. First of all, our engineering crew revises output parameters, pulse characteristics, cabinet dimensions and control logic to fit your actual on‑site production realities.
We run all our Power Supply through CE safety assessments under ISO 9001 quality‑management frameworks. Our technical staff complete 100% continuous full‑load ageing tests for every finished 300A 400V unit before shipment; therefore, purchasers receive hardware validated for stable long‑term field operation.
Our full‑lifecycle service scope includes remote commissioning guidance, spare‑parts supply and on‑site operational instruction. If you upgrade production‑line setups or adjust coating formulas, our team can modify control logic without full‑device replacement. Cooperate with Gaohui Power Supply for reliable high‑output electrophoresis Power Supply solutions.
Learn more about related products:10A 1200V Electrophoresis Rectifier
A: Products with the same nominal specifications often serve different industries, and they may carry different detailed parameter requirements. These differences directly affect production costs and technical solutions, so final prices will vary accordingly. For this reason, we recommend you contact us directly to receive a precise and tailored quotation.
A: We assign specialized consultants to support each industry sector. If you need further information, simply reach out to us. After we confirm your request, we will immediately send you the full technical datasheets and product images you need.
A: We focus on custom non-standard industrial power supplies, so we can fully adjust output current and voltage to match your exact needs. The products shown on our website only represent part of our actual range, as we do not list every model online. If you cannot find your desired specifications, please contact us directly. We will work with you to confirm your exact requirements, or we can guide you to select the most suitable parameters based on your industry standards. We will provide complete technical specifications and dimension drawings so you can fully understand the product.
