This air‑cooled electrophoresis rectifier provides high‑voltage adjustable DC output for precision coating processes. Furthermore, it runs reliably without water‑cool pipelines for light‑duty continuous production cycles.
Gaohui Power Supply manufactures the 15A 800V Air‑Cooled Electrophoresis Rectifier for high‑voltage light‑load electrophoresis workshops. To start with, certain precision‑grade coating applications call for extremely high working voltage yet relatively low current, yet many conventional water‑cool rectifiers bring extra pipeline installation burden. Because unstable high‑voltage output will result in poor film formation and surface defects on delicate parts, this Power Supply holds voltage readings stable to eliminate such production risks. What is more, it performs steadily for continuous small‑batch runs as well as intermittent trial production jobs.
This air‑cooled electrophoresis rectifier supports both cathodic and anodic electrophoresis treatments. Apart from that, its broad 0‑800V adjustment scope satisfies special high‑voltage technical requirements for thin‑film precision components. Meanwhile, optimized air‑cooled heat dissipation architecture maintains consistent performance even under long‑hour high‑voltage operating conditions inside chemical‑laden workshop surroundings.
We engineer this air‑cooled electrophoresis rectifier with compact IGBT power topology, so it achieves Power Supply conversion efficiency above ninety percent. Even working at full‑rated 800V‑15A output for long periods, its enhanced air‑cool structure controls internal temperature well and avoids over‑heat shutdown incidents. In addition, the water‑free cooling setup removes plumbing work and lowers routine maintenance workload for field operators.
Its integrated automatic polarity reversal lets staff simplify bath flushing and electrode upkeep work. As a result, operators will not need manual hardware rewiring every time production switches between process polarities. Besides, multi‑segment programming enables users to configure multi‑stage voltage‑current sequences; users can fit special high‑voltage coating formulas and achieve compatibility with multiple paint varieties.
Our technical team outfits internal circuits with corrosion‑resistant and anti‑interference electronic assemblies. Accordingly, the rectifier sustains dependable output within humid workshops filled with chemical vapour. It effectively minimises surface blemishes and uneven coating thickness triggered by external high‑frequency electrical interference.
| Parameter Category | Specific Item | Specification |
|---|---|---|
| Input Parameters | AC Input Power Supply | Three‑phase AC 380V, ±10% tolerance, 50‑60Hz |
| DC Output Parameters | Output Voltage Range | Zero to 800V adjustable |
| DC Output Parameters | Output Current Range | Zero to 15A adjustable |
| DC Output Parameters | Voltage Regulation Accuracy | Within one percent |
| DC Output Parameters | Current Regulation Accuracy | Within one percent |
| DC Output Parameters | Ripple Factor | Within two percent |
| Control and Automation Functions | Operation Modes | Constant Current, Constant Voltage |
| Control and Automation Functions | Auxiliary Control Devices | Digital ampere‑hour meter, minute‑level programmable timer, automatic polarity reversal |
| Control and Automation Functions | Programming Functions | Programmable current‑voltage ramp‑up, multi‑segment parameter setting |
| Physical and Communication Parameters | Cooling Mode | Air‑cooled |
| Physical and Communication Parameters | Protection Grade | IP21 for indoor application |
| Physical and Communication Parameters | Communication Protocol | RS485 Modbus RTU |
| Physical and Communication Parameters | Working Efficiency | Above ninety percent |
| Physical and Communication Parameters | Size and Weight | Fully customizable based on customer demands |
We can provide: We supply this unit with one‑year warranty and more than 10‑year expected service lifespan. Constant‑current / constant‑voltage modes and ramp‑up tuning belong to standard configurations. Furthermore, timed working cycles and multi‑segment parameter profiles fit special high‑voltage small‑batch coating assignments. This machine is pre‑fitted with RS485 communication interface and automatic polarity reversal function. Feel free to send over your custom Power‑Supply specifications.
This air‑cooled electrophoresis rectifier fits high‑voltage, low‑current precision metal‑finishing operations. Above all, it is well‑suited for delicate precision components, small‑lot special‑process workpieces that demand ultra‑thin uniform anti‑corrosion protective films.
Additionally, process technicians deploy this compact unit inside pilot laboratories and small‑scale production workshops without water‑cool infrastructure. Factories select this model whenever heavy‑duty water‑cool power supplies are over‑qualified for their high‑voltage low‑amp process needs.
It works compatibly with epoxy, acrylic and polyurethane electrophoresis paints for cathodic and anodic process workflows. Thanks to its stable 800V high‑voltage capability, it delivers fine, even coating coverage for intricate precision‑machined parts. Likewise, it delivers reliable performance for lab formula verification batches and intermittent small‑volume manufacturing.
Gaohui Power Supply develops custom‑adapted Air‑Cooled Electrophoresis Rectifier for precision surface‑treatment manufacturers, and application‑oriented customisation stands as our core competitive strength. First of all, our engineering group modifies output specs, pulse waveforms, cabinet dimensions and control logic to match your real‑world laboratory or shop‑floor operating conditions.
We validate all our Power Supply against CE safety standards under ISO 9001 quality‑management guidelines. Our technicians conduct 100% continuous full‑load ageing testing for every finished 15A 800V unit before dispatch; therefore, buyers receive field‑proven hardware with stable long‑run performance.
Our full‑lifecycle service includes remote commissioning guidance, spare‑parts provision and on‑site operational training. If you adjust process recipes or upgrade test‑station hardware, our team can revise control logic without complete unit replacement. Partner with Gaohui Power Supply for trusted air‑cooled high‑voltage electrophoresis Power Supply solutions.
