The 5000A 32V Water-cooled Electropolishing Power Supply provides steady high-current DC output for continuous electropolishing production. Its heavy-duty water cooling system maintains stable temperature under long-hour full-load operation.
The 5000A 32V Water-cooled Electropolishing Power Supply is a high-current industrial power source built for demanding metal electropolishing operations. Unlike conventional general-purpose rectifiers, this unit is optimized for electropolishing bath environments to maintain uniform current density across large workpieces. For example, it delivers consistent power when polishing stainless steel and alloy parts in large batch runs, and it helps you reduce waste from uneven surface finish. Many older power supplies struggle with severe thermal drift when running at 5000A full load. As a result, they create unstable output and inconsistent surface brightness, which increases reject rates and raises your overall production cost.
The 5000A 32V Water-cooled Electropolishing Power Supply supports seamless stepless adjustment from 0 to 5000A current and 0 to 32V voltage. It fits perfectly for stainless steel electropolishing, alloy surface brightening and metal deburring workflows. In addition, the closed-loop circulating water cooling system quickly dissipates heat accumulated during non-stop production cycles. It keeps the equipment within a safe operating range even during round-the-clock full-load operation. High-precision closed-loop control stabilizes DC output when workpiece surface area changes. It delivers uniform metal dissolution and keeps the electropolishing bath in stable working condition. Furthermore, multi-layer safety mechanisms protect internal hardware against overload, overheating and sudden short-circuits over long production shifts.
· Provides precise 5000A 32V stepless adjustable DC output, specially optimized for heavy-duty industrial electropolishing and metal surface brightening.
· Built with customized control logic for electropolishing processes. In turn, it maintains stable current density and delivers consistent surface finish on metal workpieces.
· Adopts heavy-duty closed-loop water cooling. Hence, it handles high continuous thermal loads and supports 24-hour uninterrupted batch manufacturing.
· Features dual CC/CV working modes. Operators can switch smoothly for pre-treatment activation, formal electropolishing and post-process inspection.
· Integrates complete industrial-grade multi-protection system. It resists unexpected current surges and safeguards both the power supply and polished metal components.
· Equipped with standard RS485 communication port. With it, users track real-time operating data and store process logs to refine electropolishing recipes.
In fact, many large metal finishing plants still rely on standard rectifier units for electropolishing lines. Those generic devices are not tuned for electropolishing bath characteristics. Even so, the 5000A 32V Water-cooled Electropolishing Power Supply meets the strict requirements of large electropolishing factories and metal surface treatment workshops. Many production lines run continuous batches with varying workpiece sizes, and this unit adapts well to these real-world working scenarios. Our team runs full-load efficiency and thermal stability testing for every unit before shipment. Therefore, each machine maintains reliable performance across repeated electropolishing batches.
Our closed-loop regulation system responds rapidly to minor output fluctuations. Changing workpiece surface area and cooling water temperature often create these small deviations. It maintains accurate current and voltage output under diverse working states. As a result, you can cut reject rates and reduce long-term power consumption. The power supply can store multiple groups of electropolishing process parameters. Operators can quickly recall validated process presets. This action shortens equipment setup time and improves overall workshop productivity.
The reinforced sealed cabinet is paired with anti-corrosion water circulation pipelines. This whole assembly delivers strong dust-proof, moisture-proof and anti-corrosion performance. Accordingly, it works reliably in the humid, corrosive atmosphere common inside electropolishing workshops. Moreover, three-phase AC input stays stable and the whole machine adopts rugged mechanical construction. This power supply has a low failure rate and long service life to fully meet uninterrupted mass production demands.
| Parameter Category | Specific Item | Specification |
|---|---|---|
| Rated Output | Rated Current | 5000A |
| Rated Output | Rated Voltage | 0‑32V |
| Working Mode | Operation Type | Constant Current / Constant Voltage, Low Ripple DC |
| Cooling System | Cooling Method | Water‑Cooled |
| Input Power | Input Voltage | Three‑phase AC Customized |
| Communication Interface | Data Port | RS485 |
| Safety Protection | Protection Functions | Over‑current, Over‑voltage, Over‑temperature, Short‑circuit, Surge Protection |
| Applicable Scenarios | Main Applications | Stainless steel electropolishing, alloy surface brightening, metal deburring, large metal part finishing |
Further, we back this power supply with a 1-year warranty and design it for over 10 years of service life. It supports constant-current and constant-voltage modes. Programmable current and voltage ramp-up also comes standard to suit different electropolishing startup workflows. Notably, multi-segment parameter settings enable flexible process configuration. Its built-in RS485 port allows staff to view live data and connect with other workshop equipment. We supply optional custom function upgrades. These options satisfy special high-current electropolishing process requirements. Reach out to us for tailored custom solutions.
The 5000A 32V Water-cooled Electropolishing Power Supply serves metal finishing manufacturers, stainless steel processing plants and industrial surface treatment workshops. Operators deploy it for large-batch electropolishing on stainless steel, nickel alloys and other metal workpieces. It also supports trial testing for newly developed electropolishing bath formulations.
Moreover, the unit runs reliably through long-duration batch cycles and round-the-clock production runs. Its optimized DC output improves surface uniformity and stabilizes electropolishing bath conditions. For instance, it minimizes surface defects such as uneven brightness and pitting, and as a result raises finished-part yield rates.
We develop custom power hardware for heavy-duty high-current electropolishing scenarios. In contrast to generic diode rectifiers, the 5000A 32V Water-cooled Electropolishing Power Supply receives specialized tuning for stable metal dissolution and continuous water-cooled batch production conditions. It delivers excellent operational stability for corrosive electropolishing workshop environments.
Our technicians complete stability simulation testing and full-load ageing checks for every unit before shipment. This step guarantees dependable real-world performance during continuous electropolishing production. We accept non-standard parameter adjustments and custom-feature development. Professional process setup guidance and complete after-sales support also come with every purchase. In short, we deliver trustworthy power hardware for your mass-production and pilot-scale metal finishing projects.
Learn more about related products：100A/12V air-cooled electrodeposition rectifier
A: Products with the same nominal specifications often serve different industries, and they may carry different detailed parameter requirements. These differences directly affect production costs and technical solutions, so final prices will vary accordingly. For this reason, we recommend you contact us directly to receive a precise and tailored quotation.
A: We assign specialized consultants to support each industry sector. If you need further information, simply reach out to us. After we confirm your request, we will immediately send you the full technical datasheets and product images you need.
A: We focus on custom non-standard industrial power supplies, so we can fully adjust output current and voltage to match your exact needs. The products shown on our website only represent part of our actual range, as we do not list every model online. If you cannot find your desired specifications, please contact us directly. We will work with you to confirm your exact requirements, or we can guide you to select the most suitable parameters based on your industry standards. We will provide complete technical specifications and dimension drawings so you can fully understand the product.
