Product Introduction

The 200A 48V continuous plating rectifier powers non-stop plating lines. It delivers stable DC power to moving workpieces. Consequently, it ensures uniform coating thickness. Therefore, it is critical for high-volume manufacturing.

Product Parameters

Product Type: High-Frequency Switching Power Supply

Rated Output: DC 0-48V / 0-200A

Input Voltage: AC Three-Phase 380V ±15%, 50/60Hz

Voltage Regulation Accuracy: ≤ ±1%

Current Regulation Accuracy: ≤ ±1%

Ripple Factor: ≤ 3% (in regulated/current mode)

Cooling Method: Air Cooling

Protection Functions: Overcurrent, Overvoltage, Overheat, Short Circuit Protection, Phase Loss Protection

Key Features & Benefits

• Dynamic Stability: This rectifier maintains set parameters despite load changes. Thus, it prevents coating variations.
• Line Speed Sync: It connects to line drive signals. Moreover, it adjusts output automatically. Consequently, it keeps current density constant.
• High-Voltage for Long Cells: The 48V output overcomes solution resistance. This ensures good current distribution.
• Industrial Reliability: Built for 24/7 operation. Additionally, it has robust cooling and protections. Therefore, it minimizes downtime.

Application Advantages

This continuous plating rectifier is essential for modern lines.

In high-speed wire plating, it ensures precise coatings at fast speeds. This is vital for product performance.

For strip plating, stability guarantees uniform results. Hence, it eliminates weak spots in components.

Ultimately, this rectifier enables higher speeds and superior consistency. It provides a direct competitive advantage.
