Single Pulse Rectifier Introduction

The 100A 12V single pulse rectifier is an industrial-grade power supply designed for high-current pulse electroplating. This single pulse rectifier delivers powerful square-wave pulses that significantly refine the microstructure of electrodeposited coatings, leading to improved performance and efficiency in production plating processes.

Product Parameters

Input Power 3-Phase 380VAC, 50/60Hz
DC Output Range 0-12V / 0-100A
Pulse Frequency 0.5 - 500 Hz
Pulse Duty Cycle 10% - 90%
Peak Current Up to 150A
Protections OCP, OVP, OTP, Short Circuit

Key Features

• High-Current Pulse Output: This single pulse rectifier provides up to 100A (150A peak) of pulse current, enabling effective grain refinement even in thick industrial coatings.
• Coating Property Enhancement: The pulsed current reduces porosity and internal stress, resulting in harder, more wear-resistant, and better-adhering deposits.
• Process Optimization: Adjustable frequency and duty cycle allow fine-tuning for different materials and desired coating characteristics.
• Production Durability: Built with industrial components and reliable cooling for continuous operation in demanding shop-floor environments.

Advantages

This 100A 12V single pulse rectifier offers clear production benefits. First, it upgrades coating quality (density, hardness) without changing bath chemistry. Second, it can increase plating speed and improve throwing power for complex parts. Third, it contributes to longer service life for plated components. Finally, it represents a reliable and efficient power solution for modern electroplating facilities.
